10ton forestry trailer with 7m Crane for Germany Description
Technical data timber trailer
• Manufacturer: Yantai Dibo Machinery Equipment Co., Ltd.
• Model: TT10,000
• Payload: 10,000 kg
• Loading area: 2.5 m²
• Tyres: 400/60-15.5
• Pendulum tandem axle
• Hydraulic articulated drawbar
• Rotating swingarm ±380°
Equipment timber trailer
• 5 pairs of stanchions • Front grille
• LED lighting with turn signal monitoring
• Air brake system
• CE Certificates
• Bottom hitch
• Adjustable towing eye Ø40 mm
• Crank support foot
Forestry crane TL7000
• Lifting torque: 61 kNm
• Swivel torque: 19 kNm
• Swivel range: 380°
• Max. operating pressure: 220 bar
• Weight: approx. 1,150 kg
• Rack and pinion slewing mechanism in oil bath
• Rotator 3 t
• Wooden grapple with 147 cm opening width
• Lifting cylinder protection
• Larger lifting cylinder for low working pressure
• Crane operation via tractor supply (load-sensing)
• 8 proportional functions
We still have more >>>>>
Feel free to get Catalogs >>>>>
All of Yantai DIBO Cranes & Trailers have approved C E certifications which strictly incompliance with European standards, our dealers have been over 30 countries in world like Austria, Slovenia,Poland, Switzerland, Sweden, Bosnia and Herzegovina, France, Germany, the United States, Canada, Ukrian,Romania, Chile, Vietnam, Brazil etc. We have our own service department which is always ready to ofreritsusupport services.
Yantai DIBO is a brand of Chinese Forest Timber Trailer Manufacture .
From the beginning, Yantai DIBO's goal has been simple: build forestry equipment that keeps working when conditions are rough. That means practical engineering, protected components, and details that support the operator's workflow-so you spend less time on downtime and more time getting work done. Yantai DIBO Exporting over 30 Europe Countries, All Trailers has approved TUV CE Certificates, today Yantai DIBO has become a recognizable brand across Europe.
